Heavy Duty 200mm Polyurethane on Nylon Swivel Braked Castor - 450kg Load
Code: 200AGH4IRPUBJSWB
Technical Information
| Load Capacity (kg) | 450kg |
| Load Capacity (kg) of 4 Castors | 1350kg |
| Overall Height | 240mm |
| Wheel Diameter | 200mm |
| Tread Width | 50mm |
| Castor Type | Swivel Braked |
| Fitting Method | Plate |
| Plate Size | 135mm x 110mm |
| Hole Centres | 105mm x 80mm |
| Hole Size | 11mm |
| Offset | 60mm |
| Bearing Type | Ball |
| Bracket Material | Fabricated |
| Wheel Material | Polyurethane on Cast Iron |
| Wheel Colour | Red |
Built for control and endurance, the Heavy Duty 200mm Polyurethane on Cast Iron Swivel Braked Castor supports 450kg loads. Its fabricated steel construction and Ball Bearing design ensure consistent, low-resistance movement. The polyurethane tread offers quiet, non-marking travel, while the cast iron core adds exceptional strength and stability. Suitable for workshop machinery, industrial carts, and transport systems requiring reliable precision with a 200mm plate design.
